zyg series gas strainer is an important device in the gas transmission and distribution system. during the gas transmission process the solid impurities in the gas are filtered to ensure the gas transmitting and distributing equipments such as pressure regulators valves flow meters pressure gauges and other instruments can work normally and not be destroyed.this series of gas strainer is a product used in conjunction with our gas turbine flowmeters and gas rotary flowmeters. it is also suitable for various pressure regulating equipment to filter dust and impurities in the gas.
this series of strainer is suitable for natural gas lpg city gas air and other gases.
products features:
● with stainless steel filter it is durable easy to clean and reusable;
● large filtration area and low fluid circulation resistance;
● filtering accurancy is optional and a differential pressure gauge that can show the dirtiness of the filter is optional;
● compact structure convenient installation and operation easy to use and maintain.
specifications:
|
model |
zyg-25 |
zyg-40 |
zyg-50 |
zyg-80 |
zyg-100 |
|
dn（mm) |
dn25 |
dn40 |
dn50 |
dn80 |
dn100 |
|
max flow（m³/h） |
80 |
100 |
150 |
400 |
650 |
|
max pressure lose（kpa) |
0.2 |
0.2 |
0.5 |
0.8 |
0.9 |
|
accuracy |
90um（180mesh），178um（mesh） |
|
pn（mpa) |
1.6 |
|
filter material |
stainless steel |
|
casing material |
cast aluminium alloy |
|
working temperature |
-30℃～ 80℃
|
boundary dimension:
|
model |
d（mm) |
l(mm) |
k(mm) |
n(pcs) |
∅(mm) |
|
zyg-25 |
∅115 |
240 |
∅85 |
4 |
14 |
|
zyg-40 |
∅150 |
270 |
∅110 |
4 |
18 |
|
zyg-50 |
∅165 |
270 |
∅125 |
4 |
18 |
|
zyg-80 |
∅200 |
330 |
∅160 |
8 |
18 |
|
zyg-100 |
∅220 |
395 |
∅180 |
8 |
18 |
