atmos^®-lora / lorawan smart electronic index for gas meter

product overview:

two-pipe diaphragm gas meter ig1 .6s-w | ig2 .5s-wiig4s-w

the lora / lorawan smart applications are growing rapidly with the in-temet of things deployment it realized collecting data from the distances of many miles or kilometers being perfect choice for suburban areas.

this smart index is meant to be attached to the existing zenner gas me-ters providing detailed energy consumption information in real-time.
the sensor starts gathering data automatically to the server after the installati-on and may be configured according to each unit.
it also helps to optimize usage of natural resources in the gas metering industry and gain substan-tial productivity.

share it

features

performance characteristics

■pre-installed long-life battery

■configurable reporting interval

■long range wireless data transmission

■maintenance free- install & forget

■communication distance (empty environment) > 5 kilometers

■conform to lorawan international standard protocol

■automatic data upload precise power consumption controlling

■remote settable block pricing and valve control

■daily and monthly billing data records available

size:
ig1.6s-w : 0.016 m³/h to 2.5 m³/h
ig2.5s-w : 0.025 m³/h to 4 m³/h
ig4s-w : 0.04 m³/h to 6 m³/h
gas media:
■natural gas
■town gas
■biogas
■liquid gas
■methane gas
housing material:
galvanized steel sheet

technical parameters

technical data atmos® ig1.6s-w \| ig2.5s-w \| ig4s-w
type			ig1.6s-w	ig2.5s-w	ig4s-w
nominal flowrate	qn	m³/h	1.6	2.5	4
maximum flowrate	qmax	m³/h	2.5	4	6
minimum flowrate	qmin	m³/h	0.016	0.025	0.04
maximum operating pressure		bar	0.5	0.5	0.5
maximum permissible errors	0.1 qmax ≤q≤ qmax qmin ≤q < 0.1 qmax		± 1.5% ± 3%	± 1.5% ± 3%	± 1.5% ± 3%
max. pressure loss		mbar	≤ 2	≤ 2	≤ 2
operating temperature		°c		-25 ~ 55
ip degree				ip65
working pressure		v		4.8~6.5
average current		μa		≤ 25
battery life		years		≥10 years (one time upload a day)
battery type				lithium battery
data storage		years		10
communication mode				lora/lorawan
the success rate of meter reading %				95
single concentrator network scale		pcs		>2000

dimensions

dimensions diaphragm gas meter atmos® ig1.6s-w | ig2.5s-w | ig4s-w

a [mm] 110 ± 0.50 130 ± 0.50 152.4 ± 0.50

b m30 x 2 - 6 g g¾b g⅞b g1b g1¼b npt ¾″ bs746 1″

c [mm] 218 226
