gprs / nb-iot/lora-wan/nfc smart diaphragm gas meter
product overview:
g1.6s-gi | g2 5s-g1| g4s-gi |wg2.5s-gi
gprs/nb iot/lora-wan/nfc gas meter is a smart gas metering product based on zenner mechanical diaphragm gas meter combined with a built-in shut-off valve basement and a smart controller with gprs/nb-iot communica-tion module.
with the connection of gprs/ nb-iot/lora-wan/nfc wireless network the following functions could be realized.
■data transmitted to cloud platform for analyzing
■block pricing
■alarm: low balance and low battery alarm temper alarm leakage alarmoverflow alarm etc.
■remote monitoring remote control
■remote valve control
■automatic shut-off valve
■combined with new media channels to achieve remote charging and real time interaction


share it

features

performance characteristics
■gprs/ nb-iot/lora-wan/nfc communication technology
■optical sampling
■fast shut-off valve
■lithium battery with more than 10 years life time
size:
g1.6s-gi: 0.016 m3/h to 2.5 m3/h
g2.5s-gi : 0.025 m3/h to 4m3/h
g4s-gi : 0.04 m3/h to 6m3/h
wg2.5s-gi: 0.016m3/h to 6m3/h
gas media:
■natural gas
■town gas
■biogas
■liquid gas
■methane gas
housing material:
galvanized steel sheet

technical parameters

technical data atmos® g1.6s-gi   g2.5s-gi | g4s-gi | wg2.5s-gi
type     g1.6s-gi g2.5s-gi g4s-gi wg2.5s-gi

nominal flowrate
qn m³/h 1.6 2.5 4 2.5

maximum flowrate
qmax m³/h 2.5 4 6 6

minimum flowrate
qmin m³/h 0.016 0.025 0.04 0.016
maximum operating pressure   bar 0.5 0.5 0.5 0.5
maximum permissible errors 0.1 qmax ≤q≤ qmax
qmin ≤q < 01qmax
  ± 1.5%
± 3%
± 1.5%
± 3%
± 1.5%
± 3%
± 1.5%
± 3%
max. pressure loss   mbar ≤ 2 ≤ 2 ≤ 2 ≤ 2
display range max.   m³/h 99999.9998 99999.9998 99999.9998 99999.9998
display range min.   m³/h 0.0002 0.0002 0.0002 0.0002
cyclic volume   dm³ 1.2 1.2 1.2 1.2
accuracy class   class 1.5 1.5 1.5 1.5
weight   kg 2.2 2.2 2.2 2.2
data acquisition     double pulse (0.1m3) or photoelectric direct
communication mode     gprs / nb-iot
communication cycle     hours days months.
battery life     lithium battery ≥ 10 years (upload once a day)
meter reading success
rate per time
    ≥ 99%

dimensions


dimensions diaphragm gas meter atmos® g1.6s-gi | g2.5s-gi | g4s-gi | wg2.5s-gi
a [mm] 110 ± 0.50 130 ± 0.50
b m30 x 2 - 6 g g¾b g⅞b g1b g1¼b npt ¾″ bs746 1″
c [mm] 218 226
