atmos®ic-card prepaid diaphragm gas meter
product overview:
two-pipe ic-card diaphragm gas meter ig1 6s | ig2.5s | ig4s
igs series are credit gas meters and use an encrypted ic card as a data carrier.
our igs system is optimally adapted to the needs of gas supply companies.
using the ic-card information such as gas flow meter status or unusual operating conditions of the meter are read.
this allows theoperator to get relevant data from the customer without on-site reading.
the gas meter is suitable for various gas media.
the integrated calibration system coordinates the movement of the valves in relation to the optimum gas flow.
the excellent linearity of the error curve is guaranteed even at low flow rates.
due to the optimum rotating characteristics of the valves the qmin value remains stable and the gas meter is resistant to contamination.
the atmos®ic-card prepaid diaphragm gas meter meets the requirements of the en1359:1998/a1 :2006 and oiml r137-1 (2012) standards.

share it

features

performance characteristics
■prepaid fundtion
■overdrawing function
■hint and warning function
■built-in shut-off valve
■anti magnetic interference
■integrated system to adjust the error curve
■starting flow< 1 dm3/h
■working temperature range: -25 °c to 55 °c .
■operating pressure. 0.5 bar
■long-term stability due to usage of high-quality diaphragms
■optional: stair gas price
■temperature and pressure compensation
sizes:
lg1.6s : 0.016 m3/hto 2.5 m3/h
ig2. 5s : 0.025 m3/h to 4m3/h
ig4s 0.04 m3/h to 6 m3/h
gas media:
■natural gas
■town gas
■biogas
■liquid gas
■methane gas
housing material:
galvanized steel sheet


technical parameters

technical data atmos® ig1.6s | ig2.5s | ig4s
type     ig1.6s ig2.5s ig4s
nominal filowrate qn m³/h 1.6 2.5 4
maximum flowrate qmax m³/h 2.5 4 6
minimum flowrate qmin m³/h 0.016 0.025 0.04
maximum operating pressure   bar 0.5 0.5 0.5
maximum permissible errors 0.1 qmax ≤q≤ qmax
qmin ≤q < 01qmax
  ± 1.5%
± 3%
± 1.5%
± 3%
± 1.5%
± 3%
max. pressure loss   mbar ≤ 2 ≤ 2 ≤ 2
display range max.   m³/h 99999.9998 99999.9998 99999.9998
display range min.   m³/h 0.0002 0.0002 0.0002
cyclic volume   dm³ 1.2 1.2 1.2
accuracy class   class 1.5 1.5 1.5
weight   kg 2.2 2.2 2.2
working voltage   vdc 4.5 / 6 4.5 / 6 4.5 / 6
battery life   year 1 1 1
pulse value   m³/pulse 0.01 or 0.1 0.01 or 0.1 0.01 or 0.1
quiescent current   μa < 20 < 20 < 20
maximum current   ma < 300 < 300 < 300

dimensions


dimensions diaphragm gas meter atmos® ig1.6s | ig2.5s | ig4s
a [mm] 110 ± 0.50 130 ± 0.50
b m30 x 2 - 6 g g¾b g⅞b g1b g1¼b npt ¾″
c [mm] 218 226
