atmos^®- diaphragm gas meter with temperature compensation

product overview:

two-pipe diaphragm gas meter g1.6-t |g2.5-t | g4-t

the gas meters g1.6-t| g2.5-t| g4-t are equipped with a temperature compensation mechanism.
when the temperature of the gas flow chan-ges a synthetic bi-metal with different thermal expansion coefficients on the compensation mechanism will be triggered.
the deformation is ben-ded so the length of the crank will be changed to adjust the movement of the diaphragm.
thereby the cyclic volume is changed. its special design will counteract the volume differences which caused by the thermal expansion and contraction of gas.
this kind of meter could improve envi-ronmental adaptability of diaphragm gas meter and greatly improve the measurement accuracy.

share it

features

performance characteristics

■temperature compensation for correcting meter readings

■integrated system to adjust the error curve

■galvanized steel powder-coated housing for maximum corrosion resistance

■operating pressure: 0.5 bar

■working temperature range. -25 °c to 55 °c

■long-term stability due to usage of high-quality diaphragms

■fire resistant (htb) up to 0.1 bar according to en1359

■anti-corrosion performance

■starting flow≤1 dm3/h

■retrofittable with pulser
sizes:
g1.6-t : 0.016 m3/h to 2.5 m3/h
g2.5-t : 0.025 m3/h to 4 m3/h
g4-t : 0.04 m3/h to 6 m3/h
gas media:
■natural gas
■town gas
■biogas
■liquid gas
■methane gas
housing material:
galvanized steel sheet

technical parameters

technical data atmos® g1.6-t \| g2.5-t \| g4-t
type			g1.6-t	g2.5-t	g4-t
nominal flowrate	qn	m³/h	1.6	2.5	4
maximum flowrate	qmax	m³/h	2.5	4	6
minimum flowrate	qmin	m³/h	0.016	0.025	0.04
maximum operating pressure		bar	0.5	0.5	0.5
maximum permissible errors	0.1 qmax ≤ q ≤ qmax qmin ≤ q < 0.1 qmax		± 1.5% ± 3%	± 1.5% ± 3%	± 1.5% ± 3%
max. pressure loss		mbar	≤ 2	≤ 2	≤ 2
display range max.		m³/h	99999.9998	99999.9998	99999.9998
display range min.		m³/h	0.0002	0.0002	0.0002
accuracy class	class		1.5	1.5	1.5
cyclic volume		dm³	1.2	1.2	1.2
pulse value		m3/pulse	0.01	0.01	0.01
weight		kg	2.0	2.0	2.0

dimensions

dimensions diaphragm gas meter atmos® g1.6-t | g2.5-t | g4-t

a [mm] 110 ± 0.50 130 ± 0.50

b m30 x 2 - 6 g g¾b g⅞b g1b g1¼b npt ¾″

c [mm] 230 238
