atmos^®xl - industrial & commercial diaphragm gas meter

product overview:

commercial gas meters g6s | g10s | g16s | g25s
the atmos^®xl series of commercial gas meter is extremely suitable for the conditions of hotels restaurants factories and other commercial set- tings.
the meter is characterized by precise measurements a constant measuring stability a long life and high reliability. thanks to the use of high-grade materials the diaphragm gas meter is resistant to corrosion. the gas meter is suitable for various gas media.
the atmos^®xl industrial & commercial diaphragm gas meter meets the requirements of the en1359:1998/a1:2006 and oiml r137-1 (2012) stan- dards.

share it

features

performance characteristics

■approved in accordance with mid by nmi

■integrated system to adjust the error curve

■galvanized powder-coated steel housing for maximum corrosion resistance

■starting flow: g6 = 8 dm/h; g10 g16= 13 dm³/h; g25 = 20 dm³/h

■working temperature range: -25 °c to 55 °c

■operating pressure: 0.5 bar

■long-term stability due to usage of high-quality diaphragms

■retrofittable with pulser

■optional: reverse flow preventer

sizes:
wg6s : 0.04 m³/hto 10 m³/h

wg10s : 0.06 m³/h to 16 m³/h

wg16s : 0.1 m³/h to 25 m³/h

wg25s : 0.16 m³/h to 40 m³/h

gas media:

■natural gas

■towngas

■biogas

■liquid gas

■methane gas

housing material:

galvanized steel sheet

technical parameters

technical data atmos® xl g6s \| g10s \| g16s \| g25s
			g6s	g10s	g16s	g25s
nominal flowrate	qn	m³/h	6	10	16	25
maximum flowrate	qmax	m³/h	10	16	25	40
minimum flowrate	qmin	m³/h	0.04	0.06	0.10	0.16
operating pressure range		kpa	0.5 ~ 50	0.5 ~ 50	0.5 ~ 50	0.5 ~ 50
cyclic volume		dm³	2.5	5	8	15
max. permissible errors	0.1 qmax ≤ q ≤ qmax 0.1qmax ≤ q ≤ qmin				± 1.5% ± 3%
maximum pressure loss		mbar	≤ 2		≤ 3
display range max.		m3/h	99999.9998		999999.998
display range min.		m3/h	0.0002		0.002
accuracy class	class		1.5	1.5	1.5	1.5
weight		kg	4.1	7.8	7.8	15.6

dimensions

dimensions commercial gas meter atmos® xl g6s \| g10s \| g16s \| g25s
		g6s	g10s	g16s	g25s
a	mm	160 ± 0.50	200 ± 0.50	240 ± 0.50	300 ± 0.50
b	mm	g1 ¼″	g2″	g2″	m80x3
c	mm	273.5	327.5	375.5	437
d	mm	254.5	316	355.5	438.8
e	mm	168.6	191	213	262.5
f	mm	192	216	238	285.5
