mechanical gas meter
features
technical parameters
| technical data atmos® hp g6a | |||
| type | hp g6a | ||
| nominal flowrate | qn | m³/h | 6 |
| maximum tlowrate | qmax | m³/h | 10 |
| minimum flowrate | qmin | m³/h | 0.06 |
| maximum operating pressure | bar | 1.5 | |
| maximum permissible errors |
0.1 qmax ≤ q ≤ qmax qmin ≤ q < 0.1 qmax |
± 1.5% ± 3% |
|
| max. pressure loss | mbar | ≤ 2 | |
| display range max. | m³/h | 99999.9998 | |
| display range min. | m³/h | 0.0002 | |
| accuracy class | class | 1.5 | |
| cyclic volume | dm³ | 2.5 | |
| pulse value | m3/pulse | 0.01 | |
| weight | kg | 3.1 | |
dimensions
| dimensions diaphragm gas meter atmos® hp g6a | |||||
| a | [mm] | 152.4 ± 0.30 | |||
| b | g1b | g1¼b | npt 1″ | npt 1¼″ | |
| c | [mm] | 279 | |||
